Are you looking for spare/service parts for the Heiniger Delta 3 clipper? Make your selection based on the service diagram of the clipper. GroomerShop.pl is an authorized warranty and post-warranty service for Heiniger clippers designed for animals. All offered parts are original service parts from the manufacturer. If you need a part that cannot be selected and/or is not shown on the diagram, please contact us, and we will verify the possibility of ordering it.
Product Code | Name
1 | SRV-HG-707-150 | Upper housing for Heiniger Delta 3 clipper
2 | SRV-HG-707-030 | Switch for Heiniger Delta 3 clipper
3 | SRV-HG-707-050 | Switch lock for Heiniger Delta 3 clipper
4 | SRV-HG-707-053 | Air filter for Heiniger Delta 3 clipper
5 | SRV-HG-707-060 | 240V motor for Heiniger Delta 3 clipper
6 | SRV-HG-707-062 | Motor stator for Heiniger Delta 3 clipper
7 | SRV-HG-707-064 | Rotor for Heiniger Delta 3 clipper
8 | SRV-HG-707-066 | PCB electronics for Heiniger Delta clipper
9 | SRV-HG-707-070 | Carbon brush for Heiniger Delta clipper
10 | SRV-HG-707-072 | Brush spring for Heiniger Delta 3 clipper
11 | SRV-HG-701-636 | Rotor bearing for Heiniger Delta clipper
12 | SRV-HG-707-074 | Brush holder for Heiniger Delta 3 clipper
13a | SRV-HG-707-075 | Mounting screw M3x50 for Heiniger Delta 3 clipper
13b | SRV-HG-707-076 | Square nut M3 for Heiniger Delta 3 clipper
13c | SRV-HG-707-077 | Lock washer M3 for Heiniger Delta 3 clipper
14 | SRV-HG-707-080 | Wire bend for Heiniger clippers
15 | SRV-HG-707-055 | Power cable for Heiniger clippers
16 | SRV-HG-707-082 | Cable holder for Heiniger clipper
17 | SRV-HG-706-524 | Circlip size 6 for Heiniger Xplorer clippers
18 | SRV-HG-707-084 | Gear for Heiniger clippers
19 | SRV-HG-707-115 | Head housing for Heiniger Delta clipper
20 | HG-706-518 | Arm/plate of the yoke for Heiniger clippers
21 | SRV-HG-706-514 | Yoke sleeve for Heiniger clippers
22 | SRV-HG-706-520 | Screw for Heiniger clippers M5 x 14
24 | SRV-HG-706-511 | Pressure arm for Heiniger clipper
25 | SRV-HG-706-525 | Guide screw M3 X 6 for Heiniger clippers
26 | SRV-HG-707-087 | Lever guide for Heiniger Delta clipper
27 | SRV-HG-706-521 | Blade mounting screw for Heiniger Delta clipper
28 | SRV-HG-707-088 | Ring/seger size 3.73mm for Heiniger Delta clipper
29 | HG-706-507 | Yoke block for Heiniger Delta clippers
30 | SRV-HG-707-089 | Crankshaft for Heiniger Delta clippers
31 | SRV-HG-707-000-31 | Crank sleeve for Heiniger Delta clipper
32 | SRV-HG-706-517 | Pressure spring for Heiniger Delta clippers
33 | SRV-HG-707-108 | Blade pressure sleeve for Heiniger Delta clipper
34 | SRV-HG-707-114 | Spacer screw for Heiniger Delta clipper
35 | SRV-HG-707-140 | Switch cover for Heiniger Delta clipper
36 | SRV-HG-707-093 | Complete head for Heiniger Delta clipper
37 | SRV-HG-707-094 | Mounting screws (KA 40 x 16) for Heiniger Delta
38 | SRV-HG-701-635 | Rotor bearing for Heiniger Delta clipper
39 | SRV-HG-701-637 | Pressure ring for Heiniger Delta clippers
40 | SRV-HG-706-523 | Screw for Heiniger Delta clippers M4 X 10
41 | SRV-HG-707-160 | Lower housing for Heiniger Delta 3 clipper
